ALL NEW R1M - BORN FROM MOTOGP

Info

INFO

ALL NEW R1M - BORN FROM MOTOGP

gambar gambar
Rp812.000.000
TypeCBU
Fuel systemFuel Injection
Fuel typePertamax
TransmissionManual
Starter systemElectric
Fuel capacity17 L
Front brakeDual hydraulic disc, Ø 310 mm
Rear brakeSingle hydraulic disc, Ø 220 mm
ColorSilver Blue Carbon
Transmission systemConstant Mesh, 6-speed
  • 17 L
  • Manual
  • 1-2
  • 1000 cc

MesinDimensiRangkaKelistrikanKredit
Mesin ✔
Engine Type liquid-cooled, in-line 4 cyliner ,4-stroke, DOHC, 4-valves
Displacement 998cm3
Bore x stroke 79.0 mm x 50.9 mm
Compression ratio 13.0: 1
Maximum power 147.1 kW (200.0PS) @ 13.500 rpm
Maximum torque 112.4 Nm (11.5) kg-m @ 11.500 rpm
Lubrication system Force-speed lubrication, wet sump
Fuel supply system Fuel Injection
Clutch type Wet, multiple-disc
Ignition system TCI
Starter system Electric
Transmission system Constant mesh 6-speed
Final drive Chain
Dimensi ✔
Overall length 2.055 mm
Overall width 690 mm
Overall height 1.150 mm
Seat height 860mm
Wheel base 1.405 mm
Minimum ground clearance 130 mm
Wet weight (including full oil and fuel tank) 199 kg
Fuel tank capacity 17 litres
Oil tank capacity 3.9 litres
Rangka ✔
Frame Almunium Deltabox
Front suspension system Upside-down telescopic fork, Ø 43 mm
Front wheel travel 120 mm
Caster Angel 24°
Trail 102 mm
Rear suspension system Swingarm (Link suspension)
Rear wheel travel 120 mm
Front brake Dual hydraulic disc, Ø 310 mm
Rear brake Single hydraulic disc, Ø 220 mm
Front tyre 120/70 ZR17M/C (58W)
Rear tyre 190/55 ZR17M/C (75W)
Kelistrikan ✔
✅Ignition system : TCI
✅Starter system : ---
Kredit ✔ Perhitungan ini hanyalah untuk tujuan simulasi saja, untuk perhitungan yang sebenarnya silahkan menghubungi Tim kami :
✅Mandala : Lihat Simulasi
✅Adira : Lihat Simulasi
✅BAF : Lihat Simulasi
✅MAF : Lihat Simulasi

Deskripsi

RACE AND TRACK READY
The new R1 is a track-focused machine with YZR-M1 DNA flowing in its veins. Its high level of equipment includes lightweight cast magnesium wheels- and for an efficient riding position the 17-litre aluminium fuel tank features deep knee recesses.

3-DIMENSIONAL CONTROL
Slide Control System (SCS), Traction Control System (TCS), Lift Control System (LIF), Quick Shift System (QSS) Launch Control System (LCS).

ABS WITH UNIFIED BRAKE SYSTEM
Sophisticated banking sensitive ABS as well as Yamaha’s Unified Brake System that enable the rider to achieve high levels of controllability in different circuit or road situations.

COMPACT DELTABOX CHASSIS
The all-new aluminium Deltabox frame features a long upward-truss type swingarm and magnesium rear frame, underlining the R1’s strong M1 race bike heritage.

HIGH-COMPRESSION CYLINDER HEAD AND LIGHTWEIGHT ENGINE
To achieve optimal performance the new engine uses a high compression 13:1 cylinder head featuring a pent roof combustion chamber with large diameter intake and exhaust valves, the R1 is equipped with titanium con rods and forged aluminium pistons.
